Attractive DIATEC low profile plastic enclosures are for wall-mount and desktop electronics and are now available in four sizes.
DIATEC is a candidate for communications and network equipment in living and working environments. Applications including computer peripherals, IoT/IIoT, gateways, data system engineering, data collection, security and access control, measurement and control, medical and laboratory technology.
These smart, modern enclosures feature a central control panel for mounting a keypad, touchscreen or display. There is a recessed area for installing and protecting interfaces, plug-in connectors and cable glands. Knockouts in the base enable easy wall mounting with no visible fixings.
DIATEC is available in two-piece (size XS) or four-piece construction (sizes S, M, L). Size XS comprises top and bottom sections that are screwed together. There is an integrated battery holder (2xAA). Sizes S, M and L each feature a top and bottom plus two snap-on covers to conceal the assembly screws. These covers can be locked to prevent tampering. The integrated battery compartment can accommodate 1×9-V or 2xAA cells.
DIATEC’s four sizes range from 5.90 in 1.46×6.10 in to 12.99×1.89×7.87 in. The enclosures are molded from ABS (UL 94 HB) in a choice of two standard colors: off-white (RAL 9002) or lava gray. Prices start at $34.
Options and accessories include hinged lids (opaque ABS, clear or translucent polycarbonate), slot-in panels to separate the electronics and terminal areas, wall suspension elements, battery clips, a 9V plug-in contact, anti-slide feet for desktop use, self-tapping screws for PCBs and a Torx T10 assembly screwdriver.
OKW can supply DIATEC fully customized. Services include CNC machining, lacquering, printing, laser marking, decor foils, special materials, RFI/EMI shielding and installation/assembly of accessories.
OKW Enclosures, Inc. 3000 Old Pond Road, Bridgeville, PA 15017, 412 220 9244, Fax: 412 220 9247, E-mail: [email protected], https://www.okwenclosures.com/en/Plastic-enclosures/Diatec.htm
